2016 Ford F-150 Box Assembly
Currently shopping for
2016 Ford F-150
Change VehicleCategories Close X
Currently selected
Body & Hardware
- Aperture Panel
- Back Panel, Hinge Pillar
- Box Assembly
- Cab Assembly
- Cab Cowl
- Carrier & Components - Spare Tire
- Cluster & Switches
- Dash Panel Components
- Ducts
- Fender & Components
- Floor
- Floor & Rails
- Frame & Components
- Front & Side Panels
- Front Bumper
- Front Console
- Front Door
- Front Door - Glass & Hardware
- Front Door - Lock & Hardware
- Front Seat Components
- Glass & Hardware - Back Glass
- Glove Box
- Grille & Components
- Hood & Components
- Information Labels
- Inner Components - Fender
- Instrument Panel Components
- Jack & Components
- Outside Mirrors
- Overhead Console
- Radiator Support
- Rear Bumper
- Rear Door
- Rear Door - Glass & Hardware
- Rear Door - Lock & Hardware
- Rear Seat Components
- Roof & Components
- Running Board
- Seat Belt
- Sound System
- Splash Shields
- Storage Compartment
- Stripe Tape & Decals
- Sunroof
- Tail Gate
- Tail Gate - Lock & Hardware
- Tracks & Components
- Trailer Hitch Components
- Windshield Glass
- Wiper & Washer Components
Other Categories
A/C & Heating
Air & Fuel Delivery
Belts & Cooling
Brakes
Charging & Starting
Driveline & Axles
Electrical
Emission Control & Exhaust
Engine
Headlights & Lighting
Interior & Exterior Trim
Maintenance & Lubrication
Steering
Suspension
Transmission
Parts Questions
Sort by:
Ref No.
Part No. & Part Description
Price & Qty.
Part No. &
Part Description
Part Description
- FL3Z-9928508-D
Box Assembly- Part Notes: 5.5 Foot Box, W/O Wheel Opening Molding, W/O Wheel Opening Molding
- FL3Z-9928508-E
Box Assembly- Part Notes: 6.5 Foot Box, W/O Wheel Opening Molding, W/O Wheel Opening Molding
FL3Z-9928508-A
Box Assembly- Part Notes: 5.5 Foot Box, W/Wheel Opening Molding, W/Wheel Opening Molding
- FL3Z-9928508-B
Box Assembly- Part Notes: 6.5 Foot Box, W/Wheel Opening Molding, W/Wheel Opening Molding
- $4600.00 $3105.001
- FL3Z-9928508-F
Box Assembly- Part Notes: 8 Foot Box, W/O Wheel Opening Molding, W/O Wheel Opening Molding
FL3Z-9900038-BA
Liner - Load Compartment- Part Notes: 45.00 LBS , Carbon Black , Moulded , With Ford Logo
- Fit Note: (+) North American Markets, With 6.5' Styleside Box
- Production Date: From 10/2014
- Callout Name: <00038
$420.00 $333.69
FL3Z-99286F74-B
Bracket- Part Notes: RH/LH
- Location: Passenger Side/Driver Side
- Fit Note: Bed Ramps
- Production Date: From 12/2014
- Require Quantity: 4
- Package Quantity: 1
- Callout Name: <286F74
$170.28 $116.98
GL3Z-99550A66-A
Net Assy - Load Fixing- Part Notes: 1.00 LBS , Horizontal
- Fit Note: (+) North American Markets, With 5.5' Styleside Box
- Production Date: From 10/2014
- Callout Name: <550A66B
$70.00 $61.16
FL3Z-99000A25-A
Kit - Hardware- Part Notes: BLACK , Lower Bed Liner Plug Kit
- Fit Note: (+) North American Markets
- Production Date: 10/2014-10/2015
- Callout Name: <000A25A
- Replaced By: FL3Z-99000A25-C
FL3Z-99000A25-C
Kit - Hardware- Part Notes: BLACK , Lower Bed Liner Plug Kit
- Fit Note: (+) North American Markets
- Production Date: From 10/2014
- Callout Name: <000A25A
$20.00 $17.63
FL3Z-9928261-A
Brace- Part Notes: Includes Instruction Sheet; Also Available At , Refer To SKFL34 9927894 For Repair Procedure
- Location: Driver Side
- Fit Note: With 5.5' Styleside Box
- Production Date: 10/2014-02/2017
- Fitting Vehicle Options: Less Phantom
- Callout Name: <28260A
- Replaced By: JL3Z-9928261-A
$25.00 $17.63
FL3Z-99402A48-AA
Step Assy - Rear- Fit Note: Tailgate - With Flexible Step
- Production Date: 10/2014-11/2016
- Callout Name: <402A48
- Replaced By: FL3Z-99402A48-AB
$1698.10 $1146.22
FL3Z-9900038-AA
Liner - Load Compartment- Part Notes: 45.00 LBS , Carbon Black , Moulded , With Ford Logo
- Fit Note: (+) North American Markets, With 5.5' Styleside Box
- Production Date: From 10/2014
- Callout Name: <00038
$420.00 $333.69
- VFL3Z-99501A42-NC
Cover - Tonneau- Part Notes: 25.00 LBS , BLACK , This Product Is Offered By Ford Component Sales As A Ford Licensed Accessory
- Fit Note: (+) North American Markets, Less Bed Ramps, With 6.5' Styleside Box
- Production Date: From 10/2014
- Callout Name: <501A42
- Replaced By: VML3Z-99501A42-D
$1219.00 $1028.53
FL3Z-99550A66-A
Net Assy - Load Fixing- Part Notes: 1.00 LBS , Envelope Type
- Fit Note: (+) North American Markets
- Production Date: From 10/2014
- Callout Name: <550A66A
$70.00 $61.16
FL3Z-9928408-AB
Reinforcement Assy - Bodyside- Part Notes: 3.00 LBS , 4 Piece Kit , Interface Plate
- Fit Note: (+) North American Markets
- Production Date: 10/2014-10/2016
- Callout Name: <28408
$65.00 $56.79
- VFL3Z-99501A42-HB
Cover - Tonneau- Part Notes: 25.00 LBS , BLACK , Entry Level Soft Roll-Up By Truxedo, This Product Is Offered By Ford Component Sales As A Ford Licensed Accessory
- Fit Note: With 8' Styleside Box-Steel
- Production Date: From 10/2014
- Callout Name: <501A42A
$389.00 $331.14
- FL3Z-9943052-B
Cable Assy - Tailgate Support- Part Notes: Non Locking , RH/LH
- Location: Passenger Side/Driver Side
- Fit Note: Bed Ramps
- Production Date: From 12/2014
- Require Quantity: 2
- Package Quantity: 1
- Callout Name: <43052
$53.73 $37.56
FL3Z-99107B72-A
Bracket- Fit Note: Tailgate - With Flexible Step
- Production Date: From 10/2014
- Callout Name: <107B72
$29.87 $21.06
- FL3Z-99286F56-A
Ramp Assy- Part Notes: RH/LH
- Location: Passenger Side/Driver Side
- Fit Note: Bed Ramps
- Production Date: From 12/2014
- Require Quantity: 2
- Package Quantity: 1
- Callout Name: <286F56
$1184.77 $799.72
VFL3Z-99000A64-B
Kit - Load Box Tie Down- Part Notes: 0.40 LBS , 2 Per Package , BLACK , This Product Is Offered By Ford Component Sales As A Ford Licensed Accessory
- Fit Note: (+) North American Markets
- Production Date: From 10/2014
- Callout Name: <000A64
FL3Z-99286A40-A
Kit- Part Notes: Kit
- Location: Passenger Side
- Fit Note: Pickup Box Extender
- Production Date: From 10/2014
- Callout Name: <286A40
$236.98 $162.81
9L3Z-99286B27-D
Bumper- Part Notes: 12MM
- Fit Note: Pickup Box Extender
- Production Date: From 10/2014
- Callout Name: <286B27
$7.02 $4.95
FL3Z-9900038-CA
Liner - Load Compartment- Part Notes: 45.00 LBS , Carbon Black , Moulded , With Ford Logo
- Fit Note: (+) North American Markets, With 8' Styleside Box-Steel
- Production Date: From 10/2014
- Callout Name: <00038
FL3Z-99286D88-B
Bolt- Fit Note: Bed Ramps
- Production Date: From 07/2015
- Require Quantity: 4
- Package Quantity: 1
- Callout Name: <286D88
$50.00 $29.13
FL3Z-99286A40-B
Kit- Part Notes: Kit
- Location: Driver Side
- Fit Note: Pickup Box Extender
- Production Date: From 10/2014
- Callout Name: <286A40
$233.92 $160.70
- FL3Z-99112A15-A
Liner - Load Compartment- Part Notes: 45.00 LBS , BLACK , Rubber Mat
- Fit Note: (+) North American Markets, With 5.5' Styleside Box
- Production Date: From 10/2014
- Callout Name: <112A15A
VFL3Z-18168-B
Kit - Lock Cylinder Repair- Part Notes: 0.50 LBS , Lock , This Product Is Offered By Ford Component Sales As A Ford Licensed Accessory
- Fit Note: (+) North American Markets
- Production Date: From 10/2014
- Callout Name: <18168
$29.00 $25.56
FL3Z-99286F56-C
Ramp Assy- Part Notes: 2 Ramp Kit , 68.00 LBS , For Spray In Liner The Tailgate Access Plate <43121 Must Be Replaced Before Installing Ramp Tailgate Plate , If The Truck Is Equipped With A Drop In Bed Liner, The Tailgate Protector (<000A38) Cannot Be Used , Required <28408 Interface Plate Kit Not Included , Trucks Equipped With Cross Box Storage Boxes Cannot Use Bed Ramps At The Same Time , Trucks Equipped With Hard Folding Tonneau Covers Cannot Use Bed Ramps At The Same Time , Weight limit 800 LBS. Per Ramp
- Fit Note: (+) North American Markets
- Production Date: From 10/2014
- Callout Name: <286F56A
FL3Z-99000A64-CA
Kit - Load Box Tie Down- Part Notes: 4 Piece Kit , 5.00 LBS , Carbon Black , Replacement Keys Are Available Thru Rotunda Only
- Fit Note: With 5.5' Styleside Box
- Production Date: 10/2014-10/2016
- Fitting Vehicle Options: Less Phantom
- Callout Name: <000A64
- Replaced By: HL3Z-99000A64-A
$110.00 $94.46
- JL3Z-99112A15-A
Liner - Load Compartment- Part Notes: Bed Tray , BLACK
- Fit Note: (+) North American Markets, Less Bed Mat, Less Load Box Bedliner, Less Pickup Box Extender, With 5.5' Styleside Box
- Production Date: From 10/2014
- Callout Name: <112A15B
- Replaced By: JL3Z-99112A15-E
$210.00 $180.34
- FL3Z-99112A15-C
Liner - Load Compartment- Part Notes: 71.00 LBS , BLACK , Rubber Mat
- Fit Note: (+) North American Markets, With 8' Styleside Box-Steel
- Production Date: From 10/2014
- Callout Name: <112A15A
FL3Z-99286F56-B
Ramp Assy- Part Notes: 40.00 LBS , For Spray In Liner The Tailgate Access Plate <43121 Must Be Replaced Before Installing Ramp Tailgate Plate , If The Truck Is Equipped With A Drop In Bed Liner, The Tailgate Protector (<000A38) Cannot Be Used , Required <28408 Interface Plate Kit Not Included , Single Ramp Kit , Trucks Equipped With Cross Box Storage Boxes Cannot Use Bed Ramps At The Same Time , Trucks Equipped With Hard Folding Tonneau Covers Cannot Use Bed Ramps At The Same Time , Weight limit 800 LBS. Per Ramp
- Fit Note: (+) North American Markets
- Production Date: From 10/2014
- Callout Name: <286F56B
- -W717968-S450B
Screw- Part Notes: 4.2 X 30
- Fit Note: Bed Ramps
- Production Date: From 12/2014
- Callout Name: HS1
$4.25 $2.50
FL3Z-99000A64-B
Kit - Load Box Tie Down- Part Notes: 4 Piece Kit , 5.00 LBS , Carbon Black , Replacement Keys Are Available Thru Rotunda Only , Required <28408 Interface Plate Kit Not Included
- Fit Note: (+) North American Markets
- Production Date: 10/2014-10/2016
- Callout Name: <000A64
- Replaced By: HL3Z-99000A64-A
$110.00 $94.46
$557.78 $379.85
