1998 Ford E-350 Econoline Information Labels

Part Notes: Kit, 12 cavity, male - for terminals contact FCS at 877-682-4276, Sensor - Transmission Range , Wiring Circuit: 12

Part Notes: 4 cavity, female, Switch - A/C Compressor Clutch Cycling
4 cavity, female, Switch - A/C Pressure Cut Off
4 cavity, female, Switch - Barometric Pressure

Part Notes: 8 cavity, female, Motor - Heater/AC Blend Door

Part Notes: 3 cavity, male, Solenoid - Brake Shift Park Interlock

Part Notes: 2 cavity, female, Coil - Ignition, 5.4, 6.8
2 cavity, female, Sensor - Camshaft Position, 4.6
2 cavity, female, Sensor - Crankshaft Position, 4.2, 4.6, 5.4, 6.8

Part Notes: 10 cavity, male, Actuator - Speed Control

Part Notes: 3 cavity, male, Alternator, except Diesel

Part Notes: 2 cavity, female, Motor - Power Window - LH - Front
2 cavity, female, Motor - Power Window - RH - Front

Part Notes: Clip 9.0mm & clamp 18mm with tether. Attach fuel supply line to fuel rail., Gas

Part Notes: 3 cavity, male, Lamp - Front Turn/Side Marker
3 cavity, male, Lamp - Park/Turn/Stop

Part Notes: 12 cavity, male, Sensor - Transmission Range

Part Notes: Cartridge type - mounts to frame, (Cutaway)

Part Notes: 3 cavity, female, Sensor - Accelerator Pedal Position
3 cavity, female, Sensor - Throttle Position

Part Notes: Located on frame rail with "9C968" fuel regulator. Element 9365, 5.4L NGV

Part Notes: Mating part- 12A581 , Wiring Circuit: 2, Color: Brown

Part Notes: 2 cavity, male, Sensor - Intake Manifold Runner Control

Part Notes: 4 cavity, male (10 gauge), Resistor - Blower Motor (Front)
4 cavity, male (10 gauge), Resistor - Blower Motor (Rear)

Part Notes: 2 cavity, male (10 gauge), Motor - Heater A/C Blower (Front)

Part Notes: Complete fuel/water separator asy. has hole in lever for attaching cable to water drain., 7.3L, BEFORE 1/12/98

Part Notes: TUBING - STEEL - 3/16" O.D. - SUPPLIED IN 25 FT. ROLLS

Part Notes: 1 cavity, male, Switch - Oil Sending Unit

Part Notes: #1831139-C91; Filter asy., fuel water separator., Diesel, FROM 1/12/98

Part Notes: 6 cavity, 5 pin to F2UZ-19986-C blower switch

Part Notes: 4 cavity, male, Sensor - Catalyst Monitor
4 cavity, male, Sensor - O2 (HEGO/ EGO)

Part Notes: (AE-110-EA) push connect, female straight, 3/8" x 5/16" connector asy., 9.5mm tube x 6.4mm hose; type 3

Part Notes: 2 cavity, male, Solenoid - EGR Vacuum Regulator

Part Notes: Clip 12.5mm & clamp 18mm with tether. Attach fuel supply line to fuel rail., Gas

Part Notes: Brake fluid warning switch, 3-pin flat connector
Courtesy light switch in door pillar, w/sliding door

Part Notes: 3 cavity, male, Lamp - Headlamp - High/Low Beam - Non-Aero

Part Notes: 4 cavity, male, Switch - Heater A/C Blower

Part Notes: 16 cavity, male, Test Connector - Diagnostic

Part Notes: 10 cavity, male, Bulkhead - Transmission - Inline

Part Notes: 2 cavity, male, Sensor - Air Charge Temperature

Part Notes: (AI-112-GA) push connect, female 3/8" x 5/16" 90 elbow asy., 9.5mm tube x 6.3mm hose; type 2

Part Notes: (AI-110-DA) push connect, female straight 5/16" connector asy., 7.9mm tube x 6.3mm hole push connect; type 3

Part Notes: "L" shaped; 34mm High x 35mm Wide x 14mm Thick.
"L" shaped; 34mm High x 35mm Wide x 14mm Thick. , (Stripped Chassis & Cutaway)

Part Notes: 2 cavity, male , Fuel Injector, 4.2, 4.6, 5.4
2 cavity, male , Switch , Brake Pressure

Part Notes: 3 cavity, female, Switch - Heater A/C Temperature Control

Part Notes: 4 cavity, male, Lamp - CHMSL (Center high Mount Stop Lamp)

Part Notes: 7 cavity, female, Switch - Multi-function (steering column)

Part Notes: 3 cavity, male, Alternator, with Diesel
3 cavity, male, Sensor - Brake Fluid Level

Part Notes: (AR-51-A) retainer, 5/16" tube push connect

Part Notes: 2 cavity, male, Valve - Vapor Management, 6.8, 5.4

Part Notes: Hose (bulk) - 5/16" tube size - 25 ft. roll

Part Notes: 3 cavity, male, Lamp - Headlamp - High/Low Beam (Aero Lamp)

Part Notes: 2 cavity, male, Motor - Idle Air Control
2 cavity, male, Motor - Windshield Washer Fluid Pump

Part Notes: Also serviced in 9155. Cap-Threaded end-fuel filter. Screws into top of 9N180. (#1831193-C91), 7.3L, FROM 1/12/98

Part Notes: Kit to add spade type starter solenoid when vehicle had spade type

Part Notes: 2 cavity, male, Speaker - Door (Front)
2 cavity, male, Speaker - Door (Rear)

Part Notes: 1 cavity, male, Capacitor - Ignition/Radio

Part Notes: 3 cavity, male, Switch - Inertia (Fuel Pump)

Part Notes: Spring lock coupling, female, sleeve - 6.35mm hose x 9.5mm push connect; type 8,

Part Notes: 5 cavity, female, Motor - Windshield Wiper

Part Notes: Gas engines, RV prep; caps F7UZ 9S303-AB, Fuel tank aux. drain tube asy., (Stripped Chassis/Cutaway)

Part Notes: Cap-Threaded end-fuel filter. Screws into top of 9N180. Also serviced in 9155., 7.3L, BEFORE 1/12/98

Part Notes: 3 cavity, female, Sensor - Delta Pressure Feedback EGR

Part Notes: 2 cavity, male (Tin terminals), Solenoid - Canister Vent

Part Notes: Plug with o'ring for access to reservoir (6658) & used on filter housing. (#1825262-C91), 7.3L, FROM 1/12/98

Part Notes: Cabar II hose material with bonded 9a064 clamp.Includes extra 9A064 clamp. Also serviced in 9034, Gas(Unleaded/leaded fuel), Midship fuel tank

Part Notes: Hose (bulk) - 3/8" tube size - 25 ft. roll

Part Notes: 4 cavity, male, gold terminals, Sensor - O2 (HEGO/ EGO), 5.4

Part Notes: F5AB-14A464-AB, mates w/12A697 air charge temp sensor, 2 cavity , Wiring Circuit: 2
F5AB-14A464-AB, mates w/9F945 solenoid cannister valve, 2 cavity , Wiring Circuit: 2
